Key Features:

• Active Balancing: Redistributes energy between cells to maintain voltage balance and extend battery life.
• Bluetooth Monitoring: Real-time monitoring of battery status, voltage, temperature, and balance via mobile app.
• Multiple Protections:
  • Overcharge protection
  • Over-discharge protection
  • Overcurrent protection
  • Short circuit protection
  • Temperature protection
• Customizable Settings: Configure thresholds for voltage, current, and temperature through the app.
• Plug-and-Play Design: Easy installation with clear labeling and included wiring harness.
• Smart Auto-Sleep Mode: Reduces power consumption when the battery is idle.
• Firmware Upgradable: Some models support firmware updates via app or PC (check version/model).

Specifications:

• Battery Type: Li-ion / LiFePO4 / LTO (selectable)
• Series Support: 4S to 8S
• Rated Discharge Current: 40A
• Rated Charge Current: 20A
• Balance Type: Active Balancing
• Balance Current: ~0.5A to 1A (varies with model and conditions)
• Communication: Bluetooth (via mobile app)
• Voltage Detection Accuracy: ±10mV
• Operating Temperature: -20°C to +70°C
• Storage Temperature: -40°C to +125°C
• Board Dimensions: Approx. 100mm x 65mm x 15mm
• Power Consumption (Standby): Low-power design (~30μA)
