Name: BMS LFP 8S 100A JBD (ZP10S036)
SKU: BL-02-BS-8660
Price: 1699 INR
Availability: InStock

0 Reviews

BMS LFP 8S 100A JBD (ZP10S036)

In stock

₹1,699.00

(Excluding IGST 18%)

The BMS LFP 8S 100A JBD (ZP10S036) is a high-quality Battery Management System designed for 8S LiFePO4 (LFP) battery packs, supporting up to 100A continuous discharge current. It ensures safe charging, discharging, and balancing, making it suitable for e-bikes, solar storage, UPS, and other high-power applications.

SKU:

BL-02-BS-8660

Categories:

Battery Management System,JBD BMS

Model: JBD (ZP10S036)
Battery Type: LiFePO4 (LFP)
Series: 8S (8 cells in series)
Nominal Voltage: 25.6V (8 × 3.2V)
Operating Voltage Range: 20V – 29.2V
Continuous Discharge Current: 100A
Peak Discharge Current: 200A (10s)
Charging Current: Up to 50A
Balance Type: Passive balancing
Balance Current: 50~100mA
Communication: UART/RS485/RS232 (depends on version)
Protection Features:
- Overcharge protection
- Over-discharge protection
- Overcurrent protection
- Short circuit protection
- Temperature protection

Dimensions:

Length: ~130mm
Width: ~65mm
Height: ~10mm
Weight: ~180g

Applications:

E-bikes and scooters
Solar energy storage
Power backup systems (UPS)
Portable power stations
High-power DIY battery packs
