BMS LFP 4S 150A JBD (CP04S024) (7d3d)

In stock
₹2,575.00
(Excluding IGST 18%)

The BMS LFP 4S 150A JBD (CP04S024) (7d3d) is a high-performance Battery Management System designed for 4S (12.8V) LiFePO4 battery packs. With a maximum continuous discharge current of 150A, it provides reliable protection against overcharge, over-discharge, overcurrent, and short-circuit. It supports cell balancing to maintain battery health and ensure long cycle life. Ideal for high-power applications like solar energy storage, electric vehicles, and inverters.

Estimated delivery:Feb 08 - Feb 12

SKU:

BL-02-BS-7180

Categories:

JBD BMS
  • Model: CP04S024 (7d3d)
  • Battery Type: LiFePO4 (LFP)
  • Series (S): 4S (12.8V nominal)
  • Continuous Discharge Current: 150A
  • Charging Current: Up to 100A
  • Balancing Current: 30–60mA (typical)
  • Protection Features: Overcharge, Over-discharge, Overcurrent, Short-circuit, Temperature
  • Communication: UART / RS485 (optional, depending on version)
  • Applications: Solar storage, EV, UPS, power tools, inverters

Dimensions

  • Length: ~130 mm
  • Width: ~65 mm
  • Thickness: ~12 mm
  • Weight: ~150 g
