BMS LFP 20S 50A JBD (TP20S001)

In stock

₹1,550.00

(Excluding IGST 18%)

The JBD LFP 20S 50A BMS (TP20S001) is a high-performance Battery Management System designed for 20S (64V nominal) LiFePO4 battery packs. It provides advanced protection features, real-time monitoring, and smart balancing to ensure battery safety, longevity, and efficiency. Ideal for energy storage systems, solar batteries, and electric vehicles.

SKU:

BL-02-BS-4141

Categories:

JBD BMS

Model: TP20S001 (732d)
Battery Type: LiFePO4 (LFP)
Series (S): 20S
Nominal Voltage: 64V
Continuous Discharge Current: 50A
Balance Function: Active/Passive cell balancing
Communication Ports: UART / RS485 / Bluetooth (optional, app monitoring support)
Protections:
- Overcharge protection
- Over-discharge protection
- Overcurrent protection
- Short-circuit protection
- Temperature protection

Dimensions & Build:

Length: ~150 mm
Width: ~100 mm
Thickness: ~20 mm
Weight: Approx. 450g
Material: High-quality PCB with aluminum heatsink for thermal management
