Name: BMS LFP 19S 60A JBD (ZP20S007)
SKU: BL-02-BS-0812
Price: 1825 INR
Availability: InStock

0 Reviews

BMS LFP 19S 60A JBD (ZP20S007)

In stock

₹1,825.00

(Excluding IGST 18%)

The BMS LFP 19S 60A JBD (ZP20S007) (73c0) is a high-performance Battery Management System designed for 19 series LiFePO4 battery packs. With a continuous discharge current of 60A, it ensures safe and efficient operation of high-capacity battery systems. It includes overcharge, over-discharge, short circuit, and temperature protection, along with Bluetooth/RS485/UART communication options for real-time monitoring. Ideal for electric vehicles, solar storage, and energy backup systems.

SKU:

BL-02-BS-0812

Categories:

JBD BMS

Model: JBD ZP20S007 (73c0)
Battery Type: LiFePO4 (LFP)
Series (S): 19S (19 cells in series)
Nominal Voltage: 60.8V (3.2V × 19S)
Charging Voltage: 69.35V (3.65V × 19S)
Continuous Discharge Current: 60A
Balance Current: ~30-60mA (passive balancing)
Protections: Overcharge, Over-discharge, Overcurrent, Short-circuit, Temperature
Communication Interface: UART / RS485 / Bluetooth (optional)
Application: E-bikes, solar energy storage, UPS, powerwall, EV batteries

📏 Dimensions

Length: ~130 mm
Width: ~100 mm
Thickness: ~20 mm
Weight: ~350 g
