Name: BMS LFP 19S 40A JBD (ZP20S007)
SKU: BL-02-BS-0754
Price: 1500 INR
Availability: InStock

0 Reviews

BMS LFP 19S 40A JBD (ZP20S007)

In stock

₹1,500.00

(Excluding IGST 18%)

The BMS LFP 19S 40A JBD (ZP20S007) (548f) is a high-performance Battery Management System designed for 19S LiFePO4 battery packs. It ensures safety, efficiency, and extended lifespan by offering overcharge, over-discharge, overcurrent, short-circuit, and temperature protection. With 40A continuous discharge current support, it is ideal for solar energy storage, EVs, UPS, and power backup systems.

SKU:

BL-02-BS-0754

Categories:

JBD BMS

Model: ZP20S007 (548f)
Battery Type: LiFePO4 (LFP)
Series (S): 19S
Nominal Voltage: 60.8V (19 × 3.2V)
Continuous Discharge Current: 40A
Charging Current: Up to 20A (configurable)
Protection Features:
- Overcharge / Over-discharge protection
- Overcurrent / Short-circuit protection
- Temperature protection
- Cell balancing function
Communication: UART / RS485 / Bluetooth (depending on version)
Applications: Solar systems, E-bikes, Energy storage packs, EVs

📌 Dimensions

Length: 120 mm
Width: 65 mm
Thickness: 15 mm
Weight: Approx. 120 g
